Produce Name: |
Urban Construction Stainless Steel Manual Globe Valve |
Key Words: |
Globe Valve |
Power: |
Hydraulic, Solenoid, Pneumatic, Manual, Electric Power+manual |
Temperature: |
Medium Temperature, Normal Temperature, High Temperature,Low Temperature |
Warrantly: |
18 Months |
Connection: |
Flanged |
Application: |
General, Oil And Gas, Petrochemical And Chemical Industry, Water And Wastewater,HVAC, C |
Media: |
Oil, Water, Gas, Air, Liquid |
Body Material: |
Stainless Steel |
Packing: |
Customized Acceptable |
Customized Support: |
OEM, ODM, OBM |
Pressure: |
150/300/600/900/1500/2500LB |
Urban Construction Stainless Steel Manual Globe Valve
Globe Valve Description
A globe valve is a valve that controls flow with a disk that moves to open or close an exit. This disk is attached to a stem, which you can move using a handle or lever.
Globe valves are handy for adjusting flow, managing pressure, and controlling temperature in many situations. They are easier to use and take care of compared to other valves and tend to leak less. This makes them suitable for a wide range of uses.
THE MAIN TECHNICAL DATAS
| Suitable medium |
Water, oil, steam |
| Working temperature |
Less than 425 centigrade |
| Nominal pressure |
PN16/25/40 |
MATERIALS OF PARTS
| Body |
WCB |
| Bonnet |
WCB |
| Gland |
WCB |
| Seal |
Stainless steel |
| Stem |
Steel 45# |
Globe Valve Performance Parmeter
| NO |
Project name |
150(Lb) |
300(Lb) |
600(Lb) |
900(Lb) |
(1500Lb) |
2500(Lb) |
| 1 |
PN(MPa) |
2.0 |
5.0 |
10.0 |
15.0 |
25.0 |
45.0 |
| 2 |
Case Test preesure(Mpa) |
3.0 |
7.5 |
15.0 |
22.5 |
37.5 |
67.5 |
| 3 |
High-pressure sealing Test pressure(Mpa) |
2.2 |
5.5 |
11.0 |
16.5 |
27.5 |
49.5 |
| 4 |
Maximum teperature Working pressure(Mpa) |
≤2.0 |
≤5.2 |
≤10.4 |
≤15.6 |
≤25.8 |
≤45.8
|
Product Features
(1) The structure is simpler than that of the gate valve, and it is easier to manufacture and maintain.
(2) The sealing surface is not easy to wear and scratch, and the sealing performance is good. There is no relative sliding between the valve disc and the sealing surface of the valve body during opening and closing, so the wear and scratch are not serious, the sealing performance is good, and the service life is long.
(3) When opening and closing, the valve stroke is small, so the original valve height is smaller than that of the gate valve, but the structural height is longer than that of the gate valve.
Who we are
SND has been producing and selling metal goods for about 20 years.By using manufacturing techniques including sand casting, lost wax casting, lost foam casting, and precision machining, the company has been supplying goods made of materials like cast iron, steel, stainless steel, aluminum, etc. Additionally offered are surface finishing and assembly services.
Our company has successfully created products in a variety of industries, including automotive, rail transportation, agricultural machinery, chemical, energy, electricity, water, air compressor, and construction, thanks to our consistent efforts over the past few years.
Our factories' ISO9001-accredited quality control systems guarantee a consistent and dependable quality for each and every component.
Spectrometer, ultrasonic, magnetic, permeability, elongation, tensile/yield strength, and other inspections are carried out as part of routine production procedures.
