Highlight:
steel flange check valve
, carbon steel flange check valve
, astm check valve dn150
Product Name: |
ASTM Standard Carbon Steel Flange Check Valve DN150 For Chemical Industry |
Key Words: |
Check Valve |
Power: |
Manual, Electric Power+manual |
Temperature: |
Medium Temperature, Normal Temperature, High Temperature,Low Temperature |
Warrantly: |
18 Months |
Connection: |
Flanged |
Application: |
Chemical Industry |
Media: |
Oil, Water, Gas, Air, Liquid |
Body Material: |
Carbon Steel |
Packing: |
Customized Acceptable |
Customized Support: |
OEM |
Pressure: |
150/300/600/900/1500/2500LB |
ASTM Standard Carbon Steel Flange Check Valve DN150 For Chemical Industry
Carbon steel flange check valve description
Carbon steel flange check valve is also called one-way valve or non-return valve, its function is to prevent the medium in the pipeline from flowing back. The opening and closing parts are automatically opened or closed by the flow and force of the medium to prevent the valve from flowing back. Check valve belongs to the automatic valve category, which is mainly used in pipelines with one-way flow of medium, and only allows the medium to flow in one direction to prevent accidents.
Main Material
| NO. |
Name |
Material |
| Chinese Standard |
ASTM Standard |
| 1 |
Body |
HT250
QT450-10 |
ASTM 126-ClassB
A536 65-45-12 |
| 2 |
Disc |
QT450-10
EPDM |
A536 65-45-12
EPDM |
| 3 |
Shaft |
1Cr13 |
ASTM 410 |
| 4 |
Cover |
HT250
QT450-10 |
ASTM 126-ClassB
A536 65-45-12 |
| 5 |
O-Ring |
EPDM |
EPDM |
| 6 |
Hand Weel |
Carbon Steel |
ASTM A570
|
Structural features of the check valve
1. Short structure length, its structure length is only 1/4~1/8 of the traditional flange check valve
2. Small size and light weight, its weight is only 1/4~1/20 of the traditional flange check valve
3. The valve disc closes quickly and the water hammer pressure is small
4. It can be used in horizontal or vertical pipelines and is easy to install
5. The flow channel is unobstructed and the fluid resistance is small
6. Sensitive action and good sealing performance
7. The valve disc has a short stroke and a small closing impact force
8. The overall structure is simple and compact, and the shape is beautiful
9. Long service life and reliable performance
Who we are
SND has been manufacturing and supplying metal products for nearly 20 years. Utilizing production methods such as sand casting, lost wax casting, lost foam casting, and precision machining, the company produces items made from materials like cast iron, steel, stainless steel, aluminum, and more. The company also provides surface finishing and assembly services.
Through years of dedicated effort, we have successfully developed products for a wide range of industries, including automotive, rail transportation, agricultural machinery, chemical, energy, power, water, air compressors, and construction.
Our factories operate under ISO9001-certified quality control systems, ensuring consistent and reliable quality for every component. Routine production processes include inspections such as spectrometer analysis, ultrasonic testing, magnetic testing, permeability checks, and evaluations of elongation, tensile strength, and yield strength.
